圆振动筛介绍
Introduction of circular vibrating screen
YA系列振动筛是一种高效新型的筛分设备，其运动轨迹近似于圆，故简称圆振动筛。我公司生产的振动筛产量能耗均达到国家标准，备受个行业用户的好评。在结构上采用了简易偏心轴激振器和偏快调节振幅。质量可靠的铆钉链接装配式几家结构提高了设备使用寿命及弹簧弹簧减震装置减小了对基础的冲击力，是一种多层高效的新型振动筛。圆振动筛型物料筛消线长，筛分规格多，各档规格筛选清晰，筛分效率高，不易堵塞，具有结构合理、激振力强、震动噪音消、坚固耐用、维修方便、使用安全等优点。
YA series vibrating screen is a new type of high-efficiency screening equipment. Its motion track is similar to a circle, so it is called circular vibrating screen for short. The energy consumption of the vibrating screen produced by our company has reached the national standard, and has been well received by users in various industries. In the structure, a simple eccentric shaft exciter and fast amplitude adjustment are adopted. The reliable quality rivet link assembly type several structures improve the service life of the equipment and the spring spring damping device reduces the impact on the foundation. It is a new type of multi-layer and high-efficiency vibrating screen. The circular vibrating screen type material has a long elimination line, multiple screening specifications, clear screening of various specifications, high screening efficiency, not easy to block, reasonable structure, strong excitation force, vibration noise reduction, sturdiness and durability, convenient maintenance, and safe use Etc.
产品优势
1. 采用偏心作为激振力，激振力强，筛分效率高。
2. 筛子横梁与筛板采用高强度螺栓链接，无焊接。
3. 震动噪音小，整机坚固耐用，使用寿命长。
4. 采用联轴器柔性链接，运转平稳，维修方便。
Product advantages
1. Using eccentricity as excitation force, strong excitation force and high screening efficiency.
2. The screen beam and the screen plate are connected by high-strength bolts without welding.
3. The vibration and noise are small, the whole machine is sturdy and durable, and the service life is long.
4. Use coupling flexible link, stable operation and convenient maintenance
工作原理
YA系列振动筛主要由筛箱、筛网、振动器、减震弹簧装置、底座等组成。
电动机经三角带使激振器偏心块产生告诉旋转。远转的偏心块产生很大的离心力，激发筛箱产生一定振幅的圆运动，晒上物料在倾斜的筛面上受到筛箱传给的冲凉儿产生连续的抛掷运动，物料与筛面相遇的过程中使小于筛孔的颗粒透筛，从而实现分级
working principle
YA series vibrating screen is mainly composed of screen box, screen mesh, vibrator, damping spring device, base and so on.
The motor makes the eccentric mass of the exciter rotate through the V-belt. The remotely rotating eccentric block produces a large centrifugal force, which stimulates the screen box to produce a circular motion with a certain amplitude. The sun-dried material on the inclined screen surface is subjected to the shower from the screen box to produce continuous throwing motion, and the material meets the screen surface. In the process, the particles smaller than the mesh are passed through the sieve to achieve classification
性能特点
1. 结构新颖，技术成熟，采用偏心块作为激振力，激振力强。
2. 采用小振幅，高频率，大倾角结构，使筛分效率高，处理量大，寿命长，垫好底，噪音消。
3. 采用弹簧钢编制筛网或冲孔筛板，使用寿命长，不易堵塞。
4. 采用轮胎联轴器，柔性链接，运转平稳。
5. 稀油润滑确保轴承始终处于最佳状态，从而彻底解决轴承发热问题，使主轴轴承保持恒温，延长维护周期和使用寿命。
Performance characteristics
1. The structure is novel, the technology is mature, the eccentric block is used as the exciting force, and the exciting force is strong.
2. The structure of small amplitude, high frequency and large angle of inclination makes the screening efficiency high, the processing capacity is large, the service life is long, the bottom is well laid, and the noise is eliminated.
3. The screen or punching screen is made of spring steel, which has a long service life and is not easy to be blocked.
4. Using tire coupling, flexible link, stable operation.
5. Thin oil lubrication ensures that the bearing is always in the best condition, thereby completely solving the problem of bearing heating, keeping the spindle bearing at a constant temperature, and extending the maintenance cycle and service life.
